High Efficiency pre-packed screen for well drilling

1.Available in oil and gas well completions, especially in an open or cased hole with unconsolidated formations where stand-alone screen is needed.
2.Pre-packed screen is easy to install for its unique construction.
3.Stainless steel material gives it ability of resisting erosion.
4.Pre-packed screen is equipped with packed layer itself. This unique configuration eliminates gravel placement and significantly shorten the time of drilling a well.
5.Stronger construction like support rods reduces maintenance costs.
6.Pre-packed screen is quite affordable in contrast to slotted liner.

Base Pipe				Gravel Pack	Perforations		Screen
OD (in.)	ID (in.)	Weight (lbs.)	Coupling OD (in.)	Thickness (in.)	Size (in.)	Holes/ft.	OD (in.)	Cylinder Area (sq. in./ft)	.006 GA Inlet Area (sq. in./ft)
1.9	1.61	2.75	2.2	0.144	3/8	84	2.72	102.49	6.46
2.063	1.75	3.25	2.5	0.144	3/8	84	2.883	108.63	6.84
2.375	1.99	4.6	2.875	0.144	3/8	96	3.195	120.39	7.58
2.875	2.44	6.4	3.5	0.144	3/8	108	3.695	139.23	8.77
3.5	2.99	9.2	4.25	0.144	3/8	132	4.32	162.78	10.26
4	3.55	9.5	4.5	0.144	3/8	144	4.82	181.62	11.44
4.5	4	11.6	5	0.144	3/8	156	5.32	200.46	12.63

If you are interested in our product, please contact us, and for more information.
