China hot sale Pre-packed screen for well drilling

Promulgator:LIDA FILTER DATE:
China hot sale Pre-packed screen for well drilling

product intro of Pre-packed screen for well drilling


pre-packed water well screen consists of one screen telescoped inside another, with an annulus filled with filter pack at the factory before shipment. The pre-packed water well screen is designed especially for high capicity wells, these screens offer unique advantages over conventional rod based screens with respect to strength. it features include: collapse strength equal to pipe; double the tensile strength of standard rod based screen; a bioresistant, hydraulically superior (to silica sand) pack; a greater percentage of open area(for deep applications) than that of a conventional screen, due to the dual support construction

Base Pipe Gravel Pack Perforations Screen
OD (in.) ID (in.) Weight (lbs.) Coupling OD (in.) Thickness (in.) Size (in.) Holes/ft. OD (in.) Cylinder Area (sq. in./ft) .006 GA Inlet Area (sq. in./ft)
1.9 1.61 2.75 2.2 0.144 3/8 84 2.72 102.49 6.46
2.063 1.75 3.25 2.5 0.144 3/8 84 2.883 108.63 6.84
2.375 1.99 4.6 2.875 0.144 3/8 96 3.195 120.39 7.58
2.875 2.44 6.4 3.5 0.144 3/8 108 3.695 139.23 8.77
3.5 2.99 9.2 4.25 0.144 3/8 132 4.32 162.78 10.26
4 3.55 9.5 4.5 0.144 3/8 144 4.82 181.62 11.44
4.5 4 11.6 5 0.144 3/8 156 5.32 200.46 12.63
5 4.41 15 5.563 0.144 3/8 168 5.82 219.3 13.82




If you are interested in our product, please contact us, and for more information.
