2016 Johnson screen

Promulgator:LIDA FILTER DATE:

2016 johnson screen ,

The V-shaped wire can be made in different height and width to address various strength application, meanwhile,
the spacing of individual slots can be varied during fabrication if geologic conditions require these variations in a
screen's construction.

Specification (wedge wire):

Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70
Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00

Specification (support rod):

Width(mm): 2.30 3.00 3.30 3.70
Height(mm): 2.70 3.60 4.70 5.60 6.30
Round: From 2.50mm to 6.0mm

Note: other specifications available as per request from our Factory

Slot size:

0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request.

Material:

galvanized low carton (LCG), stainless steel (304,316 etc.)

Length:

up to 6 meters

Diameter:

  from 25mm to 1200mm.


Advantage of our product
1 High quality
2 Direct factory
3 Prompt delievery
4 Produced as demand

Related product :Stainless Steel V Johnson wire water well screen
