water well casing screen pipe continuous slot well screen
- Promulgator：LIDA FILTER DATE:
water well casing screen pipe continuous slot well screen
Technical patameter about water well casing screen pipe continuous slot well screen for wells ,
The V-shaped wire can be made in different height and width to address various strength application,
meanwhile, the spacing of individual slots can be varied during fabrication if geologic conditions require
these variations in a screen's construction.
|
Specification (wedge wire): |
Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70 |
|
Specification (support rod): |
Width(mm): 2.30 3.00 3.30 3.70 Height(mm): 2.70 3.60 4.70 5.60 6.30 Round: From 2.50mm to 6.0mm |
|
Note: other specifications available as per request from Lida Factory |
|
|
Slot size: |
0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request. |
|
Material: |
galvanized low carton (LCG), stainless steel (304,316 etc.) |
|
Length: |
up to 6 meters |
|
Diameter: |
from 25mm to 1200mm. |
