bridged slotted screens with longitudinal welding
- Promulgator：LIDA FILTER DATE:
1.general info.( Bridge Slot Screen )
| Item desc | Bridge Slotted Screen |
| Item No. | QG-146 |
| Outer Diameter | 146 mm |
| Thickness | 3-9 mm, (be custominzed) |
| Material | AISI 304/316L(other materials can be choosed) |
| Length | 3m/pcs, 4.5m/pc (be customined) |
2.special info. ( Bridge Slot Screen )
| Aquifer classification | gravel | Rough sand | Medium sand | Fine sand | Mealy sand |
| Screening results (mm) | 1-2.5 | 0.5-1 | 0.25-0.5 | 0.1-0.25 | 0.1-0.25 |
| Bridge slots (mm) | 3 | 1.5-2 | 1 | 1 | 0.75 |
| Filling gravel spec (mm) | 4-20 | 2-8 | 2-3 | 2-3 | 2-3 |
| Filling gravel thickness (mm) | 75-100 | 100 | 100-200 | 100-200 | 100-200 |
If interested,pls contact:
Cynthia
Skype:aldfilters
Email:sales03@xxldlq.com
Mob:86-15637366455(whatsapp,viber,wechat)
